NOTE: All devices and accessories used in a Canadian installation must be Listed for use in Canada. Plug-in 120VAC transformer, ADEMCO 1321 (1321CN in Canada) or, if using Powerline Carrier devices, ADEMCO 1361X10 Transformer Module Primary telephone number messages can be reported via ECP connection to various Long Range Radios (check compatibility/availability of specific models) Rechargeable (sealed lead-acid type) 12VDC, 4AH minimum. Uses current limiting circuitry for protection.ġ2VDC, 600 mA maximum uses fuse for protection. Use ADEMCO UVS or Eagle Model 1250 can be used in conjunction with an output trigger to permit voice dialog between an operator at the central station and a person at the premises.Ĭan drive the compatible sounders steady output for burglary/panic, or temporal pulse (3 pulses – pause – 3 pulses – pause – 3 pulses.) for fire. Provides access to the system via on premises or off- premises phones for arming, disarming, etc., plus control of relay outputs and Powerline Carrier devices. Program output functions via *80 Menu mode. Use any combination of 4204, 4229 and or Powerline Carrier Devices. Output relays and/or Powerline Carrier Devices (X-10 type) Uses 5881/5883 Series Receivers/Transceivers. See Expander Module Addresses table in Wiring section and set addresses accordingly.
Zone numbers are predefined according to the device addresses used. Touch Screen (AUI) devices are in addition to the 8 addressable keypads. 6150 Fixed-Word Keypad, 6160 Alpha Keypad, 6150V Fixed-Word Display Voice Keypad, 6160V Alpha Display Voice Keypad, 6150RF Keypad/Transceiver
